SCHEMATIC AND PCB DESIGN SOFTWARE

Board design with manual routing and shape-based autorouter. Real-time DRC, high-speed and differential signals, 3D preview, STEP export, Gerber and ODB++ manufacturing output. Real-time 3D PCB preview at any stage of development. In-built 3D model generation tools and 11,000+ ready-to-use package models. STEP and VRML mechanical CAD export.
